Product configurable options
Acqiris SA220P User's Manual 7
Most of the technical specifications concerning your particular ADC card are covered in this manual,
however for the complete specifications please refer to the SA220P datasheet.
Product configurable options
The SA220P comes with several options:
Sampling rate version:
2 GS/s (default)
1 GS/s (-LSR option)
Additional memory:
4 GB (MEA option)
8 GB (MEB option)
ADC Card modes:
Digitizer mode (DGT)
Real-time averaging (AVG option)
Optional features:
Simultaneous acquisition and readout - Streaming records (CST option)
Zero Supress - Thresholding (ZS1 option)
Custom firmware capability (CFW option)
Dedicated application option:
Configuration and firmware for Swept-source OCT (SS4 option)
Other internal references:
I/O ports for SA220P: 3 I/Os, 2 analog outputs, 1 trigger output (EXA)
Limited bandwidth - for 1 GS/s version (LBW)
