7.2 How to calibrate the card?
80 Acqiris SA220P User's Manual
Group Category Parameter Calibration required
A
Acquisition Sampling rate
Only the 1st time, for an identical set of parameter
values
Channel parameters Vertical range
Input filter Bypass (Yes/No)
B Trigger Trigger source Only the 1st time
C External reference
Reference mode (External or
Internal Reference)
Each time this parameter changes
The channel parameters are calibrated independently per channel.
Driver interfaces and functions
The interfaces/methods/properties (functions/attributes) listed below are provided by the Acqiris
MD3 driver. Please refer to AqMD3.chm (IVI-C) or Acqiris.AqMD3.Fx40.chm (IVI.NET) for
detailed help.
IVI-C
Functions
AqMD3_SelfCalibrate
Attributes
AQMD3_ATTR_CALIBRATION_IS_REQUIRED
IVI.NET
Interface Method / Property name
IAqMD3Calibration
IsRequired
SelfCalibrate
