Each time the analysis process for sensor configuration is undertaken; a trace file (see below)
is automatically generated and sent out to the ECDIS-Port. This output can also be used as a
Sensor Configuration Report.
$PNAUSCA,4800,4800,4800,1
$PNAUSCD,------------ Sensor Settings ------------
$PNAUSCD,Date : 06/22/2004 08:57:05
$PNAUSCD,Hardware: AIS Transponder Class A
$PNAUSCD,Software: 2.0.0.11R3
$PNAUSCD,SW Stamp: Jun 14 2004 11:46:10
$PNAUSCD,LAT : N 53
o
30.123' LON : E 10
o
1.234'
$PNAUSCD,Heading : ExtHDT:0
o
iRot : 0
o
/min
$PNAUSCD,IMO No. : 303174162 MMSI: 2222222
$PNAUSCD,ShipName: U4 CS : D11233
$PNAUSCD,ShipType: Pilot vessel
$PNAUSCD,Length : 220m Beam: 43m
$PNAUSCD,RefPtExt: A200 B20 C10 D33m
$PNAUSCD,RefPtInt: A190 B30 C20 D23m
$PNAUSCD,Cargo : N/A or harmless
$PNAUSCD,Draught : 24.8m
$PNAUSCD,Dest. : CASABLANCA
$PNAUSCD,ETA : 10/13 12:31
$PNAUSCD,NavStat : Engaged in fishing
$PNAUSCD,EPFDType: GPS
$PNAUSCD,------------ Sensor Settings ------------
$PNAUSCD,BaudRate Sensor1: 4800 CRC:auto
$PNAUSCD,Ignored:$-----$-----$-----$-----
$PNAUSCD, :$-----$-----$-----$-----
$PNAUSCD,BaudRate Sensor2: 4800 CRC:auto
$PNAUSCD,Ignored:$HC---$-----$-----$-----
$PNAUSCD, :$-----$-----$-----$-----
$PNAUSCD,BaudRate Sensor3: 4800 CRC:auto
$PNAUSCD,Ignored:$HC---$-----$-----$-----
$PNAUSCD, :$-----$-----$-----$-----
$PNAUSCD,------------ Sensor Settings ------------
$PNAUSCD,Analyze:
$PNAUSCD,Date Src Used CHx Update
$PNAUSCD,Position: Ext $GPGLL 1 955ms
$PNAUSCD,UTC : Int $GPGGA i 952ms
$PNAUSCD,Date : Int $GPRMC i 951ms
$PNAUSCD,COG : Ext $VDVBW 1 Calc 952ms
$PNAUSCD,SOG : Ext $VDVBW 1 Calc 952ms
$PNAUSCD,Heading : Ext $TIHDT 1 953ms
$PNAUSCD,ROT : Ext $TIROT 1 949ms
$PNAUSCD,------------ Sensor Settings ------------
$PNAUSCD,Monitoring Sensor Channel 1
$PNAUSCD,[08:56:35,000] $TIROT,0.0,A
$PNAUSCD,[08:56:35,255] $GPGLL,5330.1234,N,01001
$PNAUSCD,.2345,E,141800.00,A,A
$PNAUSCD,[08:56:35,410] $GPVTG,350.0,T,,M,10.0,N
...
...
$PNAUSCD,[08:49:50,806] $TIHDT,359.9,T
$PNAUSCD,------------ ROT : ------------------
$PNAUSCD,$TIROT ext. on Ch1 :ROT
$PNAUSCD,
$PNAUSCD,Sentence : ROT Talker : TI
$PNAUSCD,Update Rate: 949ms ChkSum : N/A
$PNAUSCD,Used Fields: 1,2
$PNAUSCD, 1:Rate Of Turn
$PNAUSCD, 2:Data Valid
$PNAUSCD,
$PNAUSCD,[08:49:52,900] $TIROT,0.0,A
$PNAUSCD,[08:49:51,950] $TIROT,0.0,A
$PNAUSCD,[08:49:51,001] $TIROT,0.0,A
$PNAUSCD,
$PNAUSCD,------------ Sensor Settings ------------
