ACR Electronics AIS - Page 63

A
4
B
3
C
D
4
3
2
1
A
2
1
C
D
THIS DOCUMENT AND THE DATA DISCLOSED HEREIN OR HEREWITH IS PROPERTY OF AND
BELONGS TO ACR ELECTRONICS, INC. FT LAUDERDALE, FL. IT IS FURNISHED IN CONFIDENCE
SOLELY FOR INFORMATIONAL PURPOSES. IT IS NOT TO BE REPRODUCED, USED OR
DISCLOSED IN WHOLE OR IN PART TO ANYONE WITHOUT THE PERMISSION OF ACR.
ACR ELECTRONICS, INC
5757 RAVENSWOOD RD. FT. LAUDERDALE FL 33312
ANTENNA MOUNT
W/ HRDWRE METAL GPS4
ACR P/N 2623
SCALE
1:2
M6X1.0 HEX NUT, STAINLESS STEEL M6 SPLIT LOCK WASHER, STAINLESS STEEL FITTING, RUBBER TAPERED SPACER, UV-STABILIZED PLASTIC
FLANGE, TRIPLE-CHROMED SOLID BRASS M6X1.0X50 HEX HEAD SCREW
1
2
3 4
5
6
1
2
3
4
5
6
40
47.2
61 70
120.0°
120.0°
A A
ITEM 4
3.4
13
7.5°
7 TYP.
3 PLACES
ITEM 5
80.5
6.5
70
31
24
1"x11 1/2 NPT
3
SECTION A-A
SCALE 1 : 1
7 TYP.
3 PLACES
70
28
120°
120°
ITEM 3
2.1
Y1-03-0204 Rev. L
63
