ACR Electronics AISLink CB2 - Technical Specifications; Spares and Accessories

CB2 Manual
Y1-03-0346 Rev. B 24
8. SPECIFICATIONS
AIS transmission
Transmit Power (EIRP) 5/1Watt
Frequency Range 156.025 – 162.025MHz
Modulation AIS GMSK: BT 0.4
Receiver
Sensitivity -107dBm for 20% packet error rate
Frequency Range AIS RX1 and RX2 156.025 – 162.025MHz
Frequency Range DSC 156.525MHz
WiFi
Sensitivity 20dBm (typical)
Frequency Range 2400.0 – 2483.5MHz
General
Dimensions 101 x 162 x 58mm
4.0” x 6.4” x 2.3”
Temperature range -15°C to +55°C
5°F to 131°F
Compass Safe Distance (CB2 and GPS Antenna) 1m
Waterproof IPx7 (1 metre for 30 minutes)
Equipment category (CB2) Protected
Equipment category (GPS Antenna) Exposed
Supply Voltage Range DC 10.8V - 31.2V
GPS Receiver High Sensitivity
GPS Channels 99 acquisition/33 tracking
Serial Port Interfaces NMEA0183 (2 Rx, 2 Tx), NMEA2000 (DeviceNet), USB¹
Compliance
Standards IEC62287-2, IEC60945
¹ For maintenance/confi guration
Essential ratings information can be found on a label attached to the back of the product
9. SPARES AND ACCESSORIES
Part Number Description
ACR-9624 GPS Antenna (with 10m cable)
ACR-9625 CB2 Power Data Cable
ACR-9626 USB On the Go Adapter Cable
ACR-9627 USB A to USB micro cable
ACR-9628 USB Connector Protective Cover
