ACR Electronics AISLink CB2 - Device Connections

Y1-03-0346 Rev. B 9
CB2 Manual
2.2 Connections
! To avoid damage to the cables, ensure at least 50mm (2.0 inches)
is available below the Transceiver to allow the cables to turn.
Item Connector
1 VHF (SO239)
2 Power/Data
3 GPS Antenna (TNC)
4 NMEA2000
5 LED Indicator Button
6 USB (Micro-B)
