Acson A5CK20A User Manual

COOL
DRY
HEATMED
HIGH
AUTO
MODE
TEMP
SENSOR
ON/OFF
SLEEP
LOW
TIMER
8
2
5
9
3
6
4
1
FAN
FA
N
ON/OFF
T
EM
P
SLEEP
TIMER MODE
7
1
2
3
4
5
6
10
7
SWING
SWIN
G
FAN
SLM AC-5300 (OPTIONAL)
1. “ON/OFF” switch 6. “Sleep” mode
• Press to start the air conditioner unit. • Press button to activate the sleep
• Press again to stop the unit. function can only be activated under
“cool” or heating mode operation.
2. Temperature setting activated under “cool” mode operation, the
• Set the desired room temperature. set temperature will increase 0.5
°C after 30
• Press button to increase or decrease the minutes, 1°C after 1 hour and 2°C after 2
set temperature. Setting range are between hours. If it is actiaved under “HEAT” mode
16
°C to 30°C (60°F to 80°F). operation, the set temperature will be
descreased 0.5
°C after 30 minutes, 1°C
3. Operation Modes after 1 hour and 2°C after 2 hours.
• Press the “mode” button for select the type
of operating mode. 7. Air Swing
- Cooling Only : • Press button to activate the automatic air
COOL, DRY, FAN swing function.
- Heat Pump :
AUTO, COOL, DRY, HEAT, FAN 8. Sensor
(AUTO mode is represented by both • Infra red sensor to receive signals from
COOL and HEAT LED light on) wireless controller.
4. Fan Speed selection. 9. LED Display
• Press the button until the desired fan speed • To display the set temperature (in
°C) and
is achieved. timer delay setting (in hours).
5. Timer. 10. Transmission source
• Press the set button to select the switch • To transmit signals to the air conditioner.
timer of the air conditioner unit (the setting
range is between 1 to 10 hours).
5
