61
Outline and Dimension A5LCY-I-2010
Outline and Dimension
Outdoor Unit
Model: A5LCY 10/15DR
All dimensions are in mm
76512 638285
490
574
105.5
13
29.5
311
550
Note: Dimension in mm
Outdoor Unit
Model: A5LCY 20/25CR
Note: Dimension in mm
