Outline and Dimension A5MSY_(i)
Indoor Unit
Model: A5WMY 20/25JR
1065
310
224
310
Note: Dimension in mm
Indoor Unit
Model: A5CKY 10/15/20CR
A
Note: Dimension in mm
MODEL A B C D E F G H I J K
A5CKY 10/15/20CR 570 570 295 275 20 640 640 408 408 364 364
