Ensure that the overhead supports are
strong enough to hold the unit’s weight.
Position hanger rods and check for
alignment with the unit. Check that hangers
are secure and that the base of fan-coil unit
is level in the two horizontal directions,
taking into account the gradient
recommended for drainage flow as shown.
Check the gradient recommended for
drainage flow as follow.
Provide clearance for servicing and optimal
air flow as shown in the diagram.
The indoor unit must be installed such that
there is no short circuit of cool discharge with
air discharge. Respect the installation
clearance.
Do not put the indoor unit where there is
direct sunlight on unit. The location is
suitable for piping and drainage and it must
be have a large distance between a door
and unit.
