TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
68
MODEL
INDOOR UNIT
ADB80B
ADB80B
OUTDOOR UNIT
AMC72C
AMC80C
NOMINAL COOLING CAPACITY
Btu/h
70,000
80,000
W
20,515
23,450
NOMINAL TOTAL INPUT POWER (COOLING)
W
7,109
8,760
NOMINAL RUNNING CURRENT (COOLING)
A
13.6
15.2
EER
W/W
2.89
2.68
REFRIGERANT CONTROL (EXPANSION DEVICE)
INDOOR TXV
INDOOR TXV
REFRIGERANT CHARGE
kg
6.4
6.8
POWER SOURCE
V/Ph/Hz
ID: 220 ~ 240/1/50
OD: 380 ~ 415/3/50
ID: 220 ~ 240/1/50
OD: 380 ~ 415/3/50
REFRIGERANT TYPE
R22
R22
INDOOR UNIT
CONTROL
DUCTED
DUCTED
DUCTED
WIRED CONTROL
WIRED CONTROL
WIRED CONTROL
AIR FLOW
HIGH
CFM
2500
2500
MEDIUM
CFM
2125
2125
LOW
CFM
1750
1750
EXTERNAL
STATIC
PRESSURE
HIGH
Pa
100
100
MEDIUM
Pa
71
71
LOW
Pa
49
49
SOUND PRESSURE LEVEL (H/M/L)
dBA
50 / 50 / 48
50 / 50 / 48
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
572 X 1402 X 605
572 X 1402 X 605
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
700 X 1562 X 845
700 X 1562 X 845
UNIT WEIGHT [WITH PANEL]
kg
89
89
CONDENSATE DRAIN SIZE
mm
34
34
FAN
TYPE
CENTRIFUGAL
CENTRIFUGAL
DRIVE
DIRECT
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP20
IP20
INSULATION GRADE
F
F
RATED INPUT POWER
W
760
760
RATED RUNNING CURRENT
A
3.49
3.49
MOTOR OUTPUT
W
375 X 2
375 X 2
POLES
6
6
COIL
TUBE
MATERIAL
COPPER
COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
0.54
0.54
ROW
2
2
AIR QUALITY
FILTER
TYPE
WASAHABLE SARANET FILTER
WASAHABLE SARANET FILTER
QUANTITY
pc
2
2
CASING
COLOUR
IVORY WHITE
IVORY WHITE
OUTDOOR UNIT
AIR FLOW
CFM
6000
6000
SOUND PRESSURE LEVEL
dBA
70
74
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
946 X 1300 X 500
946 X 1300 X 500
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1132 X 1414 X 664
1132 X 1414 X 664
UNIT WEIGHT
kg
145
145
PIPE
CONNECTION
TYPE
BRAZED
BRAZED
SIZE
LIQUID
mm
12.70
12.70
GAS
mm
25.40
25.40
FAN
TYPE
PROPELLER
PROPELLER
DRIVE
DIRECT
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP44
IP44
INSULATION GRADE
F
F
RATED INPUT POWER
W
568
568
RATED RUNNING CURRENT
A
2.49
2.49
MOTOR OUTPUT
W
480
480
POLES
6
6
COMPRESSOR
TYPE
SCROLL
SCROLL
OIL TYPE
MINERAL OIL
MINERAL OIL
OIL AMOUNT
cm
3
1775
3250
RATED INPUT POWER
W
5767
7418
RATED RUNNING CURRENT
A
11.6
13.2
LOCKED ROTOR AMP.
A
101
111
COIL
TUBE
MATERIAL
SEAMLESS COPPER
SEAMLESS COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
1.23
1.23
ROW
2 X 2
2 X 2
CASING
COLOUR
IVORY WHITE
IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
