TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
89
MODEL
INDOOR UNIT
ADB500D4
OUTDOOR UNIT
A4MC125D X 4
NOMINAL COOLING CAPACITY
Btu/h
432000
W
126610
NOMINAL TOTAL INPUT POWER (COOLING)
W
53820
NOMINAL RUNNING CURRENT (COOLING)
A
93.1
EER
W/W
2.35
REFRIGERANT CONTROL (EXPANSION DEVICE)
INDOOR TXV
REFRIGERANT CHARGE
kg
10.1 X 4
POWER SOURCE
V/Ph/Hz
380 ~ 415/3/50
REFRIGERANT TYPE
R407C
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
OPERATION
WIRED CONTROL
AIR FLOW
CFM
15000
EXTERNAL STATIC PRESSURE
Pa
450
SOUND PRESSURE LEVEL
dBA
67
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1115 X 1952 X 1462
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1349 X 2208 X 1822
UNIT WEIGHT [WITH PANEL]
kg
567
CONDENSATE DRAIN SIZE
mm
34
FAN
TYPE
CENTRIFUGAL
DRIVE
BELT DRIVEN
FAN MOTOR
TYPE
INDUCTION
INDEX OF PROTECTION (IP)
IP55
INSULATION GRADE
F
RATED INPUT POWER
W
11100
RATED RUNNING CURRENT
A
18.3
MOTOR OUTPUT
W
11000
POLES
4
COIL
TUBE
MATERIAL
COPPER
DIAMETER
mm
9.52
FIN
MATERIAL
ALUMINIUM
FACE AREA
m
2
3.61
ROW
3
AIR QUALITY
FILTER
TYPE
WASAHABLE SARANET
FILTER
QUANTITY
pc
12
CASING
COLOUR
IVORY WHITE
OUTDOOR UNIT
AIR FLOW
CFM
10000
SOUND PRESSURE LEVEL
dBA
66
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1041 X 1083 X 1083
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1326 X 1277 X 1252
UNIT WEIGHT
kg
197
PIPE
CONNECTION
TYPE
BRAZED
SIZE
LIQUID
mm
15.88
GAS
mm
28.58
FAN
TYPE
PROPELLER
DRIVE
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDEX OF PROTECTION (IP)
IP44
INSULATION GRADE
F
RATED INPUT POWER
W
880
RATED RUNNING CURRENT
A
1.73
MOTOR OUTPUT
W
560
POLES
10
COMPRESSOR
TYPE
SCROLL
OIL TYPE
MINERAL OIL
OIL AMOUNT
cm
3
3253
RATED INPUT POWER
W
9800
RATED RUNNING CURRENT
A
17.0
LOCKED ROTOR AMP.
A
118.0
COIL
TUBE
MATERIAL
SEAMLESS COPPER
DIAMETER
mm
9.52
FIN
MATERIAL
ALUMINIUM
FACE AREA
m
2
2.54
ROW
2
CASING
COLOUR
IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING
INDOOR: 27°C DB / 19°C WB
OUTDOOR: 35°C DB / 24°C WB
