Acson ADB-B Series User Manual

TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
91
MODEL
INDOOR UNIT
ADB300B2
ADB300B3
OUTDOOR UNIT
A4MC150D X 2
A4MC100D X 3
NOMINAL COOLING CAPACITY
Btu/h
2900000
273000
W
85000
80010
NOMINAL TOTAL INPUT POWER (COOLING)
W
34,048
34,408
NOMINAL RUNNING CURRENT (COOLING)
A
59.2
60.2
EER
W/W
2.50
2.33
REFRIGERANT CONTROL (EXPANSION DEVICE)
INDOOR TXV
INDOOR TXV
REFRIGERANT CHARGE
kg
9.9 (x2)
7.6 (x3)
POWER SOURCE
V/Ph/Hz
380 ~ 415/3/50
380 ~ 415/3/50
REFRIGERANT TYPE
R407C
R407C
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
DUCTED
OPERATION
WIRED CONTROL
WIRED CONTROL
AIR FLOW
CFM
9000
9000
EXTERNAL STATIC PRESSURE (WITHOUT FILTER)
Pa
300
300
SOUND PRESSURE LEVEL
dBA
66
66
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1231 X1766 X 1069
1231 X1766 X 1069
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1506 X 2034 X 1412
1506 X 2034 X 1412
UNIT WEIGHT [WITH PANEL]
kg
343
343
CONDENSATE DRAIN SIZE
mm
34
34
FAN
TYPE
CENTRIFUGAL
CENTRIFUGAL
DRIVE
BELT DRIVEN
BELT DRIVEN
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP55
IP55
INSULATION GRADE
F
F
RATED INPUT POWER
W
5050
5050
RATED RUNNING CURRENT
A
9
9
MOTOR OUTPUT
W
4000
4000
POLES
4
4
COIL
TUBE
MATERIAL
COPPER
COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
1.65
1.65
ROW
5
5
AIR QUALITY
FILTER
TYPE
WASAHABLE SARANET FILTER
WASAHABLE SARANET FILTER
QUANTITY
pc
6
6
CASING
COLOUR
IVORY WHITE
IVORY WHITE
OUTDOOR UNIT
AIR FLOW
CFM
10000
7000
SOUND PRESSURE LEVEL
dBA
67
64
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1041 X 1083 X 1083
1041 X 981 X 981
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1326 X 1277 X 1252
1224 X 1175 X 1150
UNIT WEIGHT
kg
268
184
PIPE
CONNECTION
TYPE
BRAZED
BRAZED
SIZE
LIQUID
mm
15.88
15.88
GAS
mm
28.58
28.58
FAN
TYPE
PROPELLER
PROPELLER
DRIVE
DIRECT
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP44
IP44
INSULATION GRADE
F
F
RATED INPUT POWER
W
880
600
RATED RUNNING CURRENT
A
1.73
1
MOTOR OUTPUT
W
560
350
POLES
10
10
COMPRESSOR
TYPE
SCROLL
SCROLL
OIL TYPE
MINERAL OIL
MINERAL OIL
OIL AMOUNT
cm
3
4140
3253
RATED INPUT POWER
W
13619
9186
RATED RUNNING CURRENT
A
23.4
16.07
LOCKED ROTOR AMP.
A
174.0
125
COIL
TUBE
MATERIAL
SEAMLESS COPPER
SEAMLESS COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
2.82
2.26
ROW
2
2
CASING
COLOUR
IVORY WHITE
IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING
INDOOR: 27°C DB / 19°C WB
OUTDOOR: 35°C DB / 24°C WB
