Acson ADB-B Series User Manual

TECHNICAL SPECIFICATION
TS-SB-B/D-AM-A1
94
MODEL
INDOOR UNIT
ADB500B4
ADB600B4
OUTDOOR UNIT
A4MC125D X 4
A4MC150D X 4
NOMINAL COOLING CAPACITY
Btu/h
431800
580000
W
126560
170000
NOMINAL TOTAL INPUT POWER (COOLING)
W
51,078
67,293
NOMINAL RUNNING CURRENT (COOLING)
A
90.9
117.5
EER
W/W
2.48
2.53
REFRIGERANT CONTROL (EXPANSION DEVICE)
INDOOR TXV
INDOOR TXV
REFRIGERANT CHARGE
kg
7.95 (x4)
9.9 (x4)
POWER SOURCE
V/Ph/Hz
380 ~ 415/3/50
380 ~ 415/3/50
REFRIGERANT TYPE
R407C
R407C
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
DUCTED
OPERATION
WIRED CONTROL
WIRED CONTROL
AIR FLOW
CFM
15000
18000
EXTERNAL STATIC PRESSURE (WITHOUT FILTER)
Pa
380
405
SOUND PRESSURE LEVEL
dBA
68
70
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1486 x 2174 x 1336
1918 x 2174 x 1775
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1766 x 2431 x 1684
2062 x 2399 x 2005
UNIT WEIGHT [WITH PANEL]
kg
606
991
CONDENSATE DRAIN SIZE
mm
34
34
FAN
TYPE
CENTRIFUGAL
CENTRIFUGAL
DRIVE
BELT DRIVEN
BELT DRIVEN
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP55
IP55
INSULATION GRADE
F
F
RATED INPUT POWER
W
8358
9297
RATED RUNNING CURRENT
A
16.1
17.1
MOTOR OUTPUT
W
11000
11000
POLES
4
4
COIL
TUBE
MATERIAL
COPPER
COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
2.58
3.42
ROW
5
6
AIR QUALITY
FILTER
TYPE
WASAHABLE SARANET FILTER
WASAHABLE SARANET FILTER
QUANTITY
pc
6
9
CASING
COLOUR
IVORY WHITE
IVORY WHITE
OUTDOOR UNIT
AIR FLOW
CFM
10000
10000
SOUND PRESSURE LEVEL
dBA
66
67
UNIT DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1041 X 1083 X 1083
1041 X 1083 X 1083
PACKING DIMENSION
HEIGHT X WIDTH X DEPTH
mm
1326 X 1277 X 1252
1326 X 1277 X 1252
UNIT WEIGHT
kg
197
268
PIPE
CONNECTION
TYPE
BRAZED
BRAZED
SIZE
LIQUID
mm
15.88
15.88
GAS
mm
28.58
28.58
FAN
TYPE
PROPELLER
PROPELLER
DRIVE
DIRECT
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDUCTION
INDEX OF PROTECTION (IP)
IP44
IP44
INSULATION GRADE
F
F
RATED INPUT POWER
W
880
880
RATED RUNNING CURRENT
A
1.73
1.73
MOTOR OUTPUT
W
560
560
POLES
10
10
COMPRESSOR
TYPE
SCROLL
SCROLL
OIL TYPE
MINERAL OIL
MINERAL OIL
OIL AMOUNT
cm
3
3253
4140
RATED INPUT POWER
W
9800
13619
RATED RUNNING CURRENT
A
17.0
23.4
LOCKED ROTOR AMP.
A
118.0
174.0
COIL
TUBE
MATERIAL
SEAMLESS COPPER
SEAMLESS COPPER
DIAMETER
mm
9.52
9.52
FIN
MATERIAL
ALUMINIUM
ALUMINIUM
FACE AREA
m
2
2.54
2.82
ROW
2
2
CASING
COLOUR
IVORY WHITE
IVORY WHITE
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING
INDOOR: 27°C DB / 19°C WB
OUTDOOR: 35°C DB / 24°C WB
