Acson RCM 20 D User Manual

HEAT PUMP MODEL – R22
MODEL : RCM 20DR / ALC 20BR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.106 4.907 4.729 4.552 4.120 3.821 3.677 3.621 3.576
SC 4.748 4.625 4.514 4.404 3.986 3.697 3.557 3.503 3.460
15 TC 5.600 5.318 5.066 4.814 4.357 4.041 3.888 3.829 3.781
SC 4.633 4.503 4.388 4.272 3.867 3.586 3.450 3.398 3.356
18 TC 6.949 6.439 5.984 5.528 5.004 4.641 4.465 4.397 4.343
SC 4.318 4.172 4.042 3.912 3.540 3.284 3.159 3.112 3.073
19.4 TC 7.578 6.962 6.412 5.862 5.305 4.921 4.734 4.663 4.604
SC 4.172 4.018 3.881 3.744 3.388 3.143 3.024 2.978 2.941
20 TC 7.848 7.205 6.630 6.055 5.481 5.083 4.891 4.816 4.757
SC 4.109 3.943 3.796 3.648 3.302 3.062 2.946 2.902 2.866
22 TC 8.747 8.013 7.357 6.702 6.065 5.626 5.413 5.331 5.264
SC 3.899 3.694 3.512 3.329 3.013 2.794 2.689 2.648 2.615
24 TC 9.646 8.821 8.084 7.348 6.650 6.168 5.935 5.845 5.772
SC 3.689 3.445 3.228 3.010 2.724 2.527 2.431 2.394 2.364
HIGH AMBIENT
MODEL : RCM 25DR / ALC 25BR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.832 5.656 5.498 5.341 5.176 4.913 4.787 4.740 4.700
SC 4.618 4.697 4.768 4.839 4.690 4.451 4.337 4.295 4.258
15 TC 6.281 6.065 5.872 5.679 5.504 5.225 5.090 5.040 4.998
SC 4.558 4.623 4.680 4.738 4.592 4.359 4.247 4.205 4.170
18 TC 7.503 7.180 6.891 6.603 6.400 6.074 5.918 5.860 5.811
SC 4.395 4.420 4.442 4.464 4.326 4.106 4.001 3.962 3.928
19.4 TC 8.073 7.700 7.367 7.034 6.817 6.471 6.305 6.243 6.190
SC 4.319 4.325 4.330 4.336 4.202 3.989 3.886 3.848 3.816
20 TC 8.318 7.909 7.544 7.179 6.958 6.604 6.434 6.372 6.317
SC 4.286 4.260 4.237 4.214 4.084 3.876 3.777 3.740 3.708
22 TC 9.132 8.604 8.133 7.661 7.425 7.048 6.867 6.799 6.742
SC 4.177 4.044 3.926 3.807 3.690 3.503 3.413 3.379 3.351
24 TC 9.947 9.300 8.722 8.144 7.893 7.492 7.299 7.228 7.167
SC 4.068 3.829 3.615 3.401 3.296 3.129 3.048 3.019 2.993
HIGH AMBIENT
MODEL : RCM 30DR / ALC 30CR (COOLING MODE)
Indoor
DB
Indoor
WB
Capacity Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 7.547 7.272 7.027 6.782 6.457 6.117 5.853 5.710 5.559
SC 7.338 7.107 6.902 6.696 6.375 6.040 5.779 5.637 5.488
15 TC 8.219 7.848 7.516 7.184 6.840 6.480 6.200 6.048 5.888
SC 7.149 6.904 6.686 6.468 6.157 5.834 5.582 5.445 5.301
18 TC 10.053 9.417 8.849 8.281 7.884 7.469 7.147 6.972 6.787
SC 6.634 6.351 6.098 5.846 5.565 5.273 5.045 4.922 4.791
19.4 TC 10.908 10.149 9.471 8.792 8.371 7.931 7.588 7.402 7.206
SC 6.393 6.092 5.824 5.555 5.289 5.011 4.794 4.677 4.553
20 TC 11.275 10.474 9.758 9.043 8.609 8.157 7.804 7.613 7.412
SC 6.290 5.978 5.699 5.420 5.160 4.889 4.678 4.563 4.442
22 TC 12.497 11.557 10.717 9.877 9.403 8.909 8.524 8.315 8.095
SC 5.946 5.596 5.283 4.970 4.731 4.483 4.289 4.184 4.073
24 TC 13.719 12.640 11.675 10.711 10.198 9.662 9.244 9.017 8.779
SC 5.602 5.214 4.866 4.519 4.302 4.076 3.900 3.805 3.704
HIGH AMBIENT
