8 Technical specifications of the medical device
8.1 Identification
Manufacturer SATELEC, a company of Acteon group
Name of the medical device Mini LED™
8.2 Mains Adapter
Manufacturer Friwo
Supply voltage 100 - 240 VAC
Power supply frequency 50 Hz / 60 Hz
Drawn current 250 mA
Output voltage 12 V
Output current 800 mA
Width 58 mm
Height 66 mm
Depth 35.5 mm without the plug
Weight 151 g
Ingress protection rating IP 40
8.3 Optical Guide
Weight 23 g
Length 94 mm
Distal end diameter 7.5 mm
Active diameter 6.8 mm
Optical cross-section 0.36cm
2
8.4 Mini LED handpiece
Length 112 mm
Maximum outer diameter 23 mm
Weight 72 g
Ingress protection rating IPX0
Distance with user 0 cm - 70 cm
Number of LED lights 4
Wavelength range 440 nm - 460 nm
Centre wavelength 450 nm
Irradiance with opalescent optical guide 1125 mW / cm
2
- 2400 mW / cm
2
Irradiance with amber-coloured optical guide 785 mW / cm
2
- 1680 mW / cm
2
Operating mode Continuous
Safety Thermal
Type B
8.5 Technical specifications of the battery
Capacity 2500 mA / hr
Output voltage 3.7 V - 4.2 V
User Manual • Mini LED™ • J02541 • V6 • (07) • 07/2016 • NG13EN010F - Page 21/30
