ACTEON Equipment Mini LED - Charging Base; Environmental Characteristics; Environmental Restrictions; Main Performance Characteristics

Type Lithium-ion
Maximum diameter 23 mm
Length 99 mm
Weight 74 g
8.6 Charging base
Supply voltage 12 V DC
Protection 3 A / 125 V AC fuse
8.7 Environmental characteristics
Operating temperature +10°C to +30°C
Relative operating humidity 30% to 70%
Atmospheric operating pressure 800 hPa to 1060 hPa
Maximum operating altitude Equal to or less than 2000 metres
Storage temperature 0°C to +50°C
Atmospheric storage pressure 500 hPa to 1060 hPa
8.8 Environmental restrictions
Usage premises
Designed for use in all medical establishments, the medical device
cannot be used outside.
Use in gas-filled atmosphere
The Mini LED is not designed to be used in an AP or APG gas-filled
atmosphere.
Immersion The Mini LED must not be immersed.
8.9 Main performance characteristics
Wavelength between 440 and 460 nm.
Irradiance of 1125mW/cm2 to 2400mW/cm2, calculated based on the active diameter of 6.8mm with the opalescent
optical guide.
Irradiance of 785 mw / cm
2
- 1680 mW / cm
2
, calculated based on the active diameter of 6.8 mm with the amber-
coloured optical guide.
Page 22/30 - User Manual • Mini LED™ • J02541 • V6 • (07) • 07/2016 • NG13EN010F
