light guide is damaged, the M
INI L.E.D. must be
returned to the after-sales service department.
Your dealer's after sales service is at your disposal to
help with any technical problem.
9 - SPECIFICATIONS
Handpiece
Model: MINI L.E.D.
Weight: 165 g
Size: Ø23 x 200mm
Classification: Ordinary
Type B
Continuous service
IPX0
Power supply adapter
Input voltage: 110 - 240V AC
Frequency: 47 - 63 Hz
Output voltage: 12 V
Output current: 1,25 A
Classification: II
IP 40
Base station
Input voltage: 12 VDC
Protection: Fuse 2 A
Classification: Continuous service
IPX 0
Battery
Type: Lithium-Ion
Size: 90 x Ø21 mm
Capacity: 2000 mAh
Optical specifications
Wavelength: 420-480 nm
Intensity: 1250 to 2000 mW/cm² ± 10%
(depending on light guide)
class 2M laser
Temperatures
Operating: +10°C to +40°C
Storage: -20°C to +70°C
Humidity
Operating: 30% to 75%
Storage: 10% to 100% including condensation
8
ML Classic_S3 V4.qxp 13/03/2008 11:17 Page 8
