Hardware Manual
27
Connecting a Power Adapter (Optional)
The camera can be powered by a Power over Ethernet (PoE) switch that is IEEE802.3af
compliant. In case of using a non-PoE switch or your PoE switch has a limited power supply, you
can purchase a power adapter and directly connect the camera to a power outlet.
NOTE:
The power adapter is not bundled in the package.
After connecting external devices, use a waterproof tape to protect the cable
connection or house the cable inside a junction box (purchased separately).
How to Connect Audio Input / Output Devices (Optional)
If using an audio input device, such as a microphone with a built-in amplifier, connect the device
to the Mic Input jack (RED) of the camera. If using an audio output device, such as a speaker,
connect the device to the Audio Output jack (GREEN: A44, A48 or BLACK: A45, A46, A421) of
the camera.
NOTE:
Make sure that the connected audio input device has a built-in amplifier. Connecting
an ordinary microphone will dwarf sounds and will result in inaudible recording.
After connecting external devices, use a waterproof tape to protect the cable
connection or house the cable inside a junction box (purchased separately).
