This jack connects to an audio output device, such as a speaker.
See How to Connect Audio Input / Output Devices (Optional)
on page 27.
Connects the camera to an external power adapter (not
included). See A45, A46, A421
This section describes how to waterproof the Ethernet
cable of A45, A46 and A421 models using the bundled cable
gland.
Before connection, prepare an exterior-grade Ethernet cable with
RJ-45 connector but without sleeves.
NOTE: The images below are for reference only. The color or
actual cable may slightly vary.
