ACTi B4 Series - Page 5

www.acti.com
Installation Guide
5
4. Remove the sealing insert and clamping nut from the cable, and then pull out the “pigtail”
from the bracket.
5. Loosen the two (2) screws using the bundled bracket wrench to detach the bracket (B) from
the main bracket (A).
A
B
