ACTi B4 Series - Step 2: Remove the Integrated Bracket

www.acti.com
Installation Guide
4
Step 2: Remove the Integrated Bracket
1. Using the bundled camera base wrench, detach the two (2) screws to remove the bracket.
2. Remove the clamping nut and sealing insert.
3. Pull the “pigtail” from the camera.
