ACTi E41B - Page 18

www.acti.com
Hardware Manual
18
5. Attach the gland body to the Ethernet port of the camera.
IMPORTANT!
Make sure the rubber ring is completely aligned and flat on the gland body to avoid
possible water leakage.
6. Connect the Ethernet cable connector to the “pigtail” connector.
7. Insert the sealing rubber and claw into the cable gland body.
