Step 2: Install the Gang Box Converter
1. Route the network cable to pass through the hole of the gang box converter.
2. Install the gang box converter onto the gang box using the screws included in the gang
box package. Note which screw holes to attach to secure the converter to the gang box.
Screw Holes from Left to Right
Screw Holes from Right to Left
NOTE: Same screw holes apply when using the 4” octagon gang boxes.
