ACTi ECD-200 - Page 3

Quick Installation Guide 3
1
LED Indicators
- Power LED (blue)
- System LED (orange)
- Hard Disk LED (green)
2
Audio Ouput
3
Memory Card Slot
4
Audio Input
5
Reset Button
AT A GLANCE
2
3 5 6 7 8
1 2
4
9 10 11 12
6
DC 12V Power Connector
7
RS-232 Connector
8
Digital Input / Output Connector
9
USB 3.0 (2)
10
HDMI Connector
11
Ethernet Connector
12
VGA Connector
