TSE Mode
STEP 2. Place the electrodes on the skin
Place the electrodes in one of the two locations described below depending on the location of
pain.
the
For pains in both areas of the body, alternate the electrode placements between treatments.
Place one electrode at the base of the neck
. Place the other electrode in the middle of
the back as shown. Make sure
that the electrodes are directly over the spine.
e the
spinal placement.
at
T1
lower at T12
If using TSE 3 for low mood, always us
For all pains below the shoulders:
Spinal Placement
For pains in the head, neck, upper chest
and arms:
For TSE 1 and 2 modes only, place electrodes
either side of the neck as shown. There
should be a hand-width gap between the
electrodes. Remove any metallic necklaces
when using the neck placement.
If the user finds the
above neck
placement
uncomfortable, try
this alternate neck
placement with the
pads on the top of
the shoulders as
shown.
Alternate Neck Placement
Neck Placement
Do not use neck placement at
intensity settings that cause
intense tingling sensations.
Never apply the electrodes across the
head or chest, or to the front of the
neck since this can cause breathing
difficulty if the stimulation is strong
enough to cause muscle contraction.
Never use the Neck Placement with
any TENS mode. Only use with TSE at
a level at which a tingling sensation is
very mild or just perceptible.
