Technical Information
12
Standard TSE and TENS Therapy Mode Parameters
Mode Waveform Waveform Pulse Interpulse Burst Burst
Frequency Type Width Spacing Time Freq
FRQ WAVE PULS SPAC BT BF
TSE1 2.5kHz Biphasic 1.5µS 200µS OFF
TSE2 10kHz Biphasic 0.5µS 0.5µS OFF
TSE3 250Hz Biphasic 4µS 2000µS OFF
TENS1 100Hz Biphasic 50µS 0µS OFF
TENS2 5Hz Biphasic 200µS 0µS OFF
TENS3 100Hz Biphasic 100µS 0µS 100mS 5Hz
TENS4 100Hz Biphasic 100µS 0µS 500mS 1Hz
TENS5 100Hz Biphasic 10-50µS 0µS 3 sec modulation
TENS6 100Hz Biphasic 10-50µS 0µS 6 sec modulation
HFT1 500Hz Biphasic 20µS 0µS OFF
HFT2 500Hz Biphasic 20µS 0µS 50mS 10Hz
See page 26 for diagrams of Waveform shapes and Burst parameters. Modulation modes
produce a linear variation of pulse width between 10 and 50µS over the specified period.
IC Mode Program Presets
Name Carrier Base AMF Peak AMF Pattern
PROG2 4kHz 0 25 6^6
PROG4 4kHz 10 150 6^6
PROG6 4kHz 100 150 6^6
PROG8 2kHz 0 25 6^6
PROG1 4kHz 0 10 6^6
PROG3 4kHz 0 100 6^6
PROG5 4kHz 50 200 6^6
PROG7 2kHz 0 10 6^6
VAR 2kHz or 4kHz 0Hz to 250Hz 0Hz to 250Hz 1/1, 6/6, or 6^6
Programs Available (AMF= Amplitude Modulation Frequency)
Pulse width Peak Voltage
0.5 - 2µS 250V
µ
6 - 10µS 160V
3 - 5 S 200V
Pulse width Peak Voltage
µ
50µS 90V
20 S 130V
100 - 200µS 70V
TSE and TENS modes - Peak Output into 500ohms
