ActionTec T3200BV User Manual

7
T3200BV Gateway
DSL Ports (2)
The DSL ports are used to connect the Gateway to a DSL wall outlet via DSL
cable. For single line DSL, use the DSL 1 port.
Connecting the Gateway
There are many variables involved when connecting the Gateway, depending on
the type of Internet service available. The figure below shows all of the possible
connections available for the Gateway.
Power
Outlet
Power
Adapter
Coaxial
Outlet
MoCA
Cable
T3200M
Optical
Fiber
Cable
WAN Ethernet
Cable
LAN Ethernet
Cable
Ethernet
Port of
Device
WAN
Ethernet
Port
USB
Cable
USB
Port of
Device
Service
Provider
C
onnection
(Rear Panel)
DSL
Cable
DSL
Outlet
Connecting a Computer to the Gateway
To connect a computer to the Gateway to access the Gateway’s graphical user
interface (GUI):
