Active Intent GB-K6480 - Part List

NO.
DESCRIPTION SPECS. QTY
NO
...
DESCRIPTION SPECS. QTY
1 Main frame
1
48 Power wire socket
1
2 Base frame
1
49 Power wire
1
3 Upright bracket
2
50
Overload protector
1
4 Incline bracket
1
51 Single wire 1
1
5 Computer bracke t
1
52 AC single wire
1
6
Running board strengthen
tube
2
53 Single wire
1
7 Tubing assembly
1
54 Grounding wire
1
8
Front roller
1
55 Silicone oil
1
9 Rear roll er
1
56 Lock nut
M6 6
10 5# Allen wrench
1
57 Lock nut
M8 8
11 6# Allen wrench
1
58 Lock nut
M10 12
12 Wrench with screw driver
1
59 Bolt
M8*25 4
13 cylinder
1
60 Bolt
M6*40 4
14
Motor top cover
1
61 Bolt
M8*65 3
15 M
otor bottom cover
1
62 Bolt
M8*16 6
16 Side rail
2
63 Bolt
M10*42 1
17 Left ba ck end cap
1
64 Bolt
M10*55 1
18 Right back end cap
1
65 Bolt
M8*40 4
19 Running belt
1
66 Bolt
M10*45 4
20 Computer top cover
1
67 Bolt
M10*45 2
21 Computer bottom cover
1
68 Bolt
M8*45 2
22 Panel
1
69 Bolt
M8*25 1
23 Left hand bar
1
70 Bolt
M8*42
3
24 Right hand bar
1
71 Bolt
M5*8 1
25 Running belt
2
72 Screw
4.2*20 2
26 wheel
2
73 Screw
4.2*25 4
27 Left ba se cover
1
74 Screw
4.2*19 18
28 Right ba se cover
1
75 Scre
w
4.2*25 4
29 Distance sleeve
8
76 Screw
4.2*19 3
30 Moving wheel
2
77 Screw
4.2*9.5 2
31 Foot pa
d
4
78 Screw
4.2*30 4
32 Safety key
1
79 Screw
4.2*25 4
33 Isolation nylo n pad
4
80 Screw
4.2*40 2
34 cushion
4
81 Screw
4.2*12
5
35 Strengthen tub e cushion
4
82 Screw
4.2*13 13
36 Ring wire protector A
1
83 Lock washer
10 8
37 Ring wire protector B
1
84 Flat washer
8 2
38 Oil plug
1
85 Spring washer
8 2
39 Motor belt
1
86 Lock washer
5 2
40 Running board
1
87
41 DC motor
1
88
Lock washer
8 13
42 Incline motor
1
89
Spring washer
5 2
43 Control bo ard
1
90
44 Computer top wire
1
91
45
Computer bottom wire
1
92
46 Magnetic ring
1
93
47 Switch
1
94
Part list
