Actron CP7527 Inductive - Timing Mark Location and Cycle Setting

TDC
UDC 1-6
16N
OP 1-6
O
A
3
6
10
0
DC
10
10
IMPORTANT
5. Locate the Timing Marks on the Engine
· The Digital Timing Light is equipped with
a flashlight feature. Press and hold the
button for continuous lighting.
6. Set 2/4 CYCLE OPERATION (Digital
Timing Light Only)
· Use 2-cycle mode on 2-cycle engines and
on vehicles equipped with waste-spark
distributorless ignition systems (DIS).
When connected to the battery, the timing light defaults to the 4-
cycle, tachometer mode.
· Press and release button until correct indicator lights.
