ActronAir ESP Plus SRV201E - Page 30

Installation and Commissioning Guide - Split Ducted ESP Plus/Ultima Indoor Unit
Doc. No.0525-078 Ver. 2 190925
30
Installation and Commissioning Guide
Split Ducted ESP Indoor Unit
On Board Sensor Only
ZONE CONTROL
LMZC2
LINK
P1
DATA CABLE FROM
ULTIMA MODULE
8ZVAV
ZONE
MOTOR
MODULATION
ZONING
ZONE
4
ZONE
3
ZONE
2
ZONE
1
ZONE
8
ZONE
7
ZONE
6
ZONE
5
ULTIMA MODULE
Part No. 8Z-VAV
AMIB
DATA
LOG
NOTE: DO NOT REMOVE LINK
One Zone Sensor Only
DATA CABLE FROM
ULTIMA MODULE
8ZVAV
ZONE SENSOR
LMZS2
ZONE
MOTOR
MODULATION
ZONING
ZONE
4
ZONE
3
ZONE
2
ZONE
1
ZONE
8
ZONE
7
ZONE
6
ZONE
5
ULTIMA MODULE
Part No. 8Z-VAV
AMIB
DATA
LOG
One Zone Control and One Zone Sensor (Zone Temperature Averaging)
RJ45 3WAY
CABLE HOLDER
IMPORTANT:
SEE NOTE BELOW
MODULATION
ZONING
ZONE
4
ZONE
3
ZONE
2
ZONE
1
ZONE
8
ZONE
7
ZONE
6
ZONE
5
ULTIMA MODULE
Part No. 8Z-VAV
AMIB
DATA
LOG
ZONE SENSOR
LMZS2
DATA CABLE FROM
ULTIMA MODULE
8ZVAV
ZONE
MOTOR
ZONE CONTROL
LMZC2
LINK
P1
NOTE: DO NOT REMOVE LINK
One Zone Control and One Zone Sensor (Zone Control Sensor is ignored)
RJ45 3WAY
CABLE HOLDER
IMPORTANT:
SEE NOTE BELOW
MODULATION
ZONING
ZONE
4
ZONE
3
ZONE
2
ZONE
1
ZONE
8
ZONE
7
ZONE
6
ZONE
5
ULTIMA MODULE
Part No. 8Z-VAV
AMIB
DATA
LOG
ZONE SENSOR
LMZS2
DATA CABLE FROM
ULTIMA MODULE
8ZVAV
ZONE
MOTOR
ZONE CONTROL
LMZC2
LINK
P1
NOTE: REMOVE LINK
IMPORTANT NOTES
Communication cable between 8-zone Ultima module and RJ45 3-Way cable joiner must not exceed 175mm (RJ45 3-Way joiner is
supplied with 175mm cable).
