ActronAir ESP Plus SRV201E - 15. Zone Control And Sensor Mounting Dimensions

39
Installation and Commissioning Guide
Split Ducted ESP Indoor Unit
Installation and Commissioning Guide - Split Ducted ESP Plus/Ultima Indoor Unit
Doc. No.0525-078 Ver. 2 190925
15. Zone Control And Sensor Mounting Dimensions
15.01. Zone Control (LM-ZC-2) - ESP Ultima Only
Note: Drawn not to scale
101.5
mm
60mm
24mm
17mm
25mm
72.5 mm
12
mm
60mm
25mm
24mm
17mm
15.02. Zone Sensor (LM-RS-2 / LM-ZS-2)
Note: Drawn not to scale (LM-ZS-2 shown below, dimensions are the same with LM-RS-2).
9.5
mm
21mm21mm
63
mm
41 mm
21mm
21mm
22mm
