ActronAir LM Series Service Manual

10
LM7 / LM7-D / LM24 / LM24W Service Manual
Version 4.0 140402
LM SERIES CONTROL / INSTALLATION DIAGRAM
LM-SERIES CONTROLLER WITH OPTIONAL 4 ZONE 230VAC ZONE CARD (AMZ)
6
2 CORE 14/0.20 (0.44mm)
Shielded Data Cable
R
®
NOTES:
1. DIAGRAM SHOWN ABOVE IS A GENERAL PRESENTATION ONLY. REFER TO INDIVIDUAL UNIT WIRING
DIAGRAM FOR COMPLETE WIRING CONNECTION DETAILS AND SPECIFICATIONS.
2. NOT APPLICABLE TO ESP PLUS & ESP ULTIMA MODEL SERIES.
OPTIONAL
WALL CONTROLLER 2
(MIMIC LOGIC)
WALL CONTROLLER 1
CONDENSER CPU BOARD
SENSOR
KEY
COMMON
POWER
SENSOR
KEY
COMMON
POWER
OUTDOOR UNIT
INDOOR UNIT
INDOOR BOARD
OPTIONAL
4 - ZONE 230VAC ZONE CARD
(AMZ)
EARTH
NC NO NC NO NC NO NC NO
NEUT
NEUT
NEUT NEUT
ZONE 1
ZONE 1
ZONE 2
ZONE 2
ZONE 3
ZONE 3
ZONE 4
ZONE 4
NEUT ACT RLY Z4Z4Z4Z4
3
rd
PARTY 230VAC ZONE BARRELS
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
E
DATA /
COM / B
S - 2
S - 1/G
KEY/Y
P W R
AMIB-3
COM / B
COIL OUT
A B C D E
COIL IN
EXV
G A B
SCRN
HIGH
MID
LOW
NEUT
A N E
ActronAir
INDOOR FAN 230V
2020-XXX
AMIB-PXXX
PCB S/N
P.3.X.1.0.0
NEUT NEUT NEUT NEUT
LOW
HIGH
ACT
ETH
COMP
LP
LP
HP
REV
HP
N2132
COM
NEUT
ACT
DATA
SCRN
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
2 CORE 14/0.20 (0.44mm)
Shielded Data Cable
4 - ZONE AMZ CARD COMPATIBILITY
INDOOR BOARD AMZ 230VAC CARD
AMIB-P * Yes
* Available to all R410A split residential
models, except ESP Ultima &
ESP Platinum Ultima
AERSS
OPTIONAL
DUCT BEAD SENSOR
(Supplied with Cable)
LM-RS
OPTIONAL
REMOTE
SENSOR
Field Wiring by Installer
Cable must be 2 CORE 14/0.20 (0.44mm
2
) Screened Cable
or 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair Shielded Cable
4 CORE 14/0.20 (0.44mm)
Shielded Data Cable
Field Wiring by Installer
2 CORE & EARTH CABLE (230VAC)
Cable must be 2 CORE 7/0.30 (0.5mm
2
) Twisted Pair
Shielded Data Cable
