9
ActronAir
®
is constantly seeking ways to improve the design of it’s products, therefore specifi cations are subject to change without notice. Please check prior to purchase.
Copyright © 2014 Actron Engineering Pty. Ltd.
LM SERIES CONTROL / INSTALLATION DIAGRAM
LM-D CONTROLLER WITH ULTIMA 8 ZONE 24VAC ZONE MODULE (8Z-VAV)
OUTDOOR UNIT
R
®
NOTES:
1. DIAGRAM SHOWN ABOVE IS A GENERAL PRESENTATION ONLY. REFER TO INDIVIDUAL UNIT WIRING
DIAGRAM FOR COMPLETE WIRING CONNECTION DETAILS AND SPECIFICATIONS.
2. APPLICABLE TO ESP PLATINUM ULTIMA MODEL SERIES ONLY.
OPTIONAL
8-ZONE 24VAC INTEGRATED ZONE BARRELS
(ZB-10-250 / ZB-12-300 / ZB-14-350 / ZB-16-400)
OPTIONAL
8-ZONE 24VAC ZONE MODULE
(8Z-24V)
OPTIONAL
WALL CONTROLLER 2
(MIMIC LOGIC)
WALL CONTROLLER 1
CONDENSER CPU BOARD
OPTIONAL
ACTRONAIR ZONE BARREL CABLES
CAT5E Cable with Fully Moulded RJ45 Plug
SENSOR
KEY
COMMON
POWER
SENSOR
KEY
COMMON
POWER
INDOOR
BOARD
4 CORE 14/0.20 (0.44mm)
Shielded Data Cable
Field Wiring by Installer
2 CORE 7/0.30 (0.5mm
2
) Twisted Pair Shielded Cable
with Screen Foil clamped to a Metal P-Clip
TO VSD
Field Wiring by Installer
2 CORE & EARTH CABLE
(230VAC)
Screen Foil Clamped into a
Metal P-Clip
8Z-VAV ZONE MODULE COMPATIBILITY
INDOOR BOARD 8Z-VAV
AMIB-PVVM * Yes
* Available to ESP Platinum Ultima
Models only.
ROOM
TEMP
MODE
ON/OFF
SET
ZONE COOL HEAT
ESP
OFF
AUTO
MAX
C
TEMP
ZONE CONTROL
ROOM
TEMP
MODE
ON/OFF
SET
ZONE COOL HEAT
ESP
OFF
AUTO
MAX
C
TEMP
ZONE CONTROL
ROOM
TEMP
MODE
ON/OFF
SET
ZONE COOL HEAT
ESP
OFF
AUTO
MAX
C
TEMP
ZONE CONTROL
LM-ZC
OPTIONAL
ZONE
CONTROL
LM-ZC
OPTIONAL
ZONE
CONTROL
LM-ZS
OPTIONAL
ZONE
SENSOR
1-Zone
Up To
8-Zone
Options
INDOOR UNIT
E
A
N
E
ActronAir
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
2020-131
DATA /
COM / B
S - 2
S - 1/G
KEY/Y
P W R
COM / B
SCRN
AMIB-PVVM ERM
S/N: XXXXXXX
™
COMP
HEAT
FAN
15V
ON
11
2345678
WARNING
DAMAGE DUE TO
INCORRECT WIRING
VOIDS WARRANTY
(8Z-VAV)
™
To Next Page
