Rain Gauge Installation
• To ensure accurate rain measurement, the rain gauge MUST be
placed on a at, level surface.
• Ensure the rain gauge is not placed in a low spot that could become
ooded or in an area where there are obstructions above it.
OK
1. Separate the rain gauge cover from the rain gauge base.
2. Locate the two holes on the rain gauge base.
3. Fasten the rain gauge base to a sturdy surface, like a deck railing or a fence
post, with screws (included) using hand tools. (Power tools may slip during
installation, causing damage to the rain gauge.)
INSTALL 2 SCREWS USING
HAND TOOLS ONLY.
THEN RE-ATTACH UPPER CASING
SQUEEZE
SQUEEZE TABS TO OPEN
Setup is Complete
The rain gauge will now synchronize with the display. It may take a few minutes
for synchronization to complete. Please refer to the troubleshooting section of this
manual if anything appears to be functioning improperly.
