Optional Wiring
AAccuummeenn rreeccoommmmeennddss tthhaatt tthhee ffoolllloowwiinngg wwiirreess aarree ccoonnnneecctteedd ttoo ggeett ffuullll
bbaassiicc ooppeerraattiioonn ooff tthhee CCAATT33..11 SSyysstteemm,, hhoowweevveerr,, tthheeyy aarree nnoott ccrriittiiccaall ttoo tthhee
ooppeerraattiioonn ooff tthhee ssyysstteemm..
Flashing Indicators
The two
PPIINNKK
wires are for the indicators. Connect one Pink wire to the LH
indicator, and the other Pink wire to the RH indicators. Ensure you connect
these wires to the positive side of the indicators - if you connect to the
negative side of the indicators the alarm fuse will fail. Acumen recommend
these connections are soldered.
Flashing LED
The paired
BBllaacckk//RReedd
wires with the two-way connector are for the LED
system indicator. Connect the two plugs together.
Movement Sensing Nudge Facility
The two
BBLLUUEE
wires - one with a male connector on it, one with a female
connector - are to remove/add the nudge facility of the movement sensing.
• If the two blue wires are connected, the nudge sensing is added.
• Dis-connecting these two wires removes the nudge sensing.
Optional Wiring Connections
(not required for basic operation)
The
YYEELLLLOOWW//GGRREEEENN
wire is the Pager wire. It supplies 12v at 0.5A when the
alarm is reacting. It is designed to connect to the Acumen AlarmMate Pager
(Acumen Pt No 10114) and/or the Acumen external siren (Acumen Pt No
10115) .
IIMMPPOORRTTAANNTT
IIff tthhiiss wwiirree sshhoorrttss ttoo GGrroouunndd wwhhiillee tthhee aallaarrmm iiss ssoouunnddiinngg tthhee aallaarrmm EECCUU wwiillll bbee
ddaammaaggeedd..
The
PPUURRPPLLEE
wire is the alarm antenna. It should be extended along a plastic
component and taped into position. Do not tape within the wiring harness and
do not connect to ground/earth.
The
GGRREEEENN
wire is the trigger wire for the optional Immobilisation relay.
Instructions for connection are included in the immobilisation kit. If you are
not using it, tape the wire to the main harness in a tidy fashion.
The
WWHHIITTEE
wire is an optional Trigger wire. If you need to use this circuit, the
alarm will trigger if the switch you add to this circuit changes it’s state. (ie;
open to closed, or closed to open) Connect the wire to a switch and the other
side of the switch to a suitable ground. When the switch changes the alarm
will sound. It can be connected to items such as a magnetic reed seat switch,
or pressure mat under the m/c side stand, or the Acumen garage kit.
See www.acumen-electronics.co.uk
NNOOTTEE
If a poor connection is made in this circuit the alarm will interpret any
change of state - regardless of how short in time - as an alarm and will react
accordingly. Make sure all connections are sound, waterproof and cannot
short.
3
