Check the fluid level with the engine
at normal operating temperature.
Park the vehicle on level ground.
Shut off the engine.
Remove the dipstick (yellow loop)
from the transmission and wipe it
with a clean cloth.
Insert the dipstick all the way into
the transmission.
Remove the dipstick and check
the fluid level. It should be
between the upper and lower
marks.
If the level is below the lower
mark, remove the fill plug and add
fluid to bring it to the upper mark.
Always use Honda ATF-Z1
(Automatic Transmission Fluid). If
it is not available, you may use a
DEXRON
III automatic
transmission fluid as a temporary
replacement. However, continued
use can affect shift quality. Have
the transmission drained and
refilled with Honda ATF-Z1 as
soon as it is convenient.
To thoroughly flush the
transmission, the technician
should drain and refill it with
Honda ATF-Z1, then drive the
vehicle a short distance. Do this
three times. Then drain and refill
the transmission a final time.
Insert the dipstick all the way back
in the transmission.
The transmission should be drained
and refilled with new fluid according
to the time and distance recommen-
dations in the maintenance schedule.
Ifyouarenotsurehowtoaddfluid,
contact your Acura dealer.
1.
2.
3.
5.
6.
4.
Maintenance
Automatic Transmission Fluid
271
UUPPPPEERR MMAARRKK
LLOOWWEERR MMAARRKK
DDIIPPSSTTIICCKK
DDIIPPSSTTIICCKK
00/08/07 22:29:16 31S3V600_276
