The spark plugs in your vehicle are a
special platinum-tipped design for
longer life. The spark plugs should
be replaced according to the time
and distance recommendations in
the maintenance schedule.
Loosen the two holding clips by
turning the heads one-quarter turn
counterclockwise with a flat-tipped
screwdriver. Remove the cover on
the front cylinder bank by pulling
it straight up.
Clean up any dirt and oil that have
collected around the ignition coils.
Clean the hood latch assembly with a
mild cleaner, then lubricate it with a
multipurpose grease. Lubricate all
the moving parts (as shown),
including the pivot. Follow the time
and distance recommendations in
the Maintenance Schedule. If you
are not sure how to clean and grease
the latch, contact your Acura dealer.
1.
2.
CONTINUED
Hood Latch Spark Plugs
Replacement
Hood Latch, Spark Plugs
Maintenance
277
LLAATTCCHH AASSSSEEMMBBLLYY
HHOOLLDDIINNGG CCLLIIPP
00/08/08 15:45:50 31S3V600_282
