Disconnect the wire connector
from the ignition coil by pushing
on the lock tab and pulling on the
connector. Pull on the plastic
connector, not the wires.
Remove the spark plug with
a five-eighths inch (16 mm) spark
plug socket.
Use a wrench to remove the
hexagonsocketheadcapbolt
holding the ignition coil. Remove
the ignition coil by pulling it
straight out.
Put the new spark plug into the
socket; then screw it into the hole.
Screw it in by hand so you do not
crossthread it.
3. 4.
5.
6.
Maintenance
Spark Plugs
278
HHEEXXAAGGOONN SSOOCCKKEETT HHEEAADD CCAAPP BBOOLLTT
00/08/07 22:30:16 31S3V600_283
