Carefully pry in the top or bottom
edge of the trim with a small flat-
tip screwdriver, and pull the trim
straight back.
Open the trunk lid, and remove
the left or right maintenance lid.
Remove the mounting nut with an
8mmwrench.
Pull the taillight assembly straight
back out of the body.
Remove the two mounting bolts
with an 8 mm wrench.
Insert the new bulb into the hole,
and turn it one-quarter turn
clockwise to lock it in place.
Push the electrical connector back
onto the bulb. Make sure it is on
all the way.
Turn on the fog lights to test the
new bulb.
Reinstall the two undercover bolts
on the side under cover and
tighten them securely. Put the
holding clip back on the side
undercover and push on the center
until it locks (the center is flush
with the head).
2.
1. 3.
4.
5.
5.
6.
7.
8.
CONTINUED
Replacing a Rear Turn Signal
Light Bulb
Lights
Maintenance
473
MOUNTING NUT
MAINTENANCE LID
TAIL LIGHT TRIM
BOLTS
11/07/20 19:02:33 31SJA670_478
