421
uuBefore DrivinguMaximum Load Limit
In addition, the total weight of the vehicle, all occupants,
accessories, cargo, and trailer tongue load must not exceed the
Gross Vehicle Weight Rating (GVWR) or the Gross Axle Weight
Rating (GAWR). Both are on a label on the driver’s doorjamb.
1Maximum Load Limit
Towing a Trailer:
See Towing a Trailer to determine whether your
vehicle is designed to tow a trailer.
2 Towing a Trailer P. 422
Load Limits Example
Example1
Max Load
1,173 lbs
(532 kg)
Passenger Weight
150 lbs x 2 = 300 lbs
(68 kg x 2 = 136 kg)
Cargo Weight
873 lbs
(396 kg)
Example2
Max Load
1,173 lbs
(532 kg)
Passenger Weight
150 lbs x 5 = 750 lbs
(68 kg x 5 = 340 kg)
Cargo Weight
423 lbs
(192 kg)
24 ACURA MDX-31TYA6200.book 421 ページ ２０２３年３月２日 木曜日 午後１２時４４分
