713
uuFusesuFuse Locations
Located on the battery in the cargo area.
Remove the cover.
2 Checking the Battery P. 637
Push the tabs to open the box.
Fuse locations are shown on the fuse box
cover. Locate the fuse in question by the
fuse number and box cover number.
Replacement of the fuses should be done by
a dealer.
■
Rear Fuse Box Type B
*
Circuit Protected Amps
B Battery 450 A
C − 150 A
D Jump Start Box 200 A
E − 80 A
F Rear Fuse Box 1 70 A
G Fuse Box 2 60 A
H Rear Fuse Box 2 70 A
* Not available on all models
24 ACURA MDX-31TYA6200.book 713 ページ ２０２３年３月２日 木曜日 午後１２時４４分
