ADA MB-1 owners manual version 2
PRECAUTIONS
WARNING: To prevent fire or shock hazard, do not expose this appliance to rain or
moisture. Keep the MB-1 out of direct sunlight. Avoid locations subject
to vibration, excessive dust, heat, or cold.
CAUTION: To prevent electric shock, do not remove cover. No user serviceable
parts inside. Refer servicing to qualified service personnel.
RETAIN INSTRUCTIONS: Keep this manual for future reference.
CLEANING: Do not clean your MB-1 with chemical solvents. Use only a
clean, dry cloth.
QUICK SET -UP
Note: The MB-1 is a preamp and must be connected to a power amp in order to drive loud
speakers.
Note: If you are using the complete ADA Bass Amplification System (MB-1, B500B,
BASSLINE 15, and BASSLINE HX), set all rear panel controls to the points indicated by
white dots.
INITIAL PREPARATION:
1. Connect bass guitar output to front panel input jack.
2. Connect MB-1 output(s) to input(s) on power amplifier(s)
3. Connect power amp output(s) to speaker cabinet(s) input(s), Note: use speaker
cable(s) for this connection.
4. Turn MB-1 power switch ON.
5. Turn power amp on.
6. Adjust volume with Output level control.
SELECT PROGRAM NUMBER:
1. Use the up and down arrow buttons to scroll thru the memory numbers 1 thru79.
These are the Factory Preset Programs.
2. Select a bank by pressing the BANK button, use the up or down arrow button to
select bank 0 thru 7, followed by any button 0 thru 9 for program number within the
selected bank, (1 thru 9 in bank 0).
SELECT MIDI CHANNEL:
1. Press MIDI CHANNEL button.
2. Use up and down arrows to select MIDI channel from 1 to 16, ALL (OMNI), or OFF
(MIDI reception off.)
3. Press MIDI CHANNEL button to store channel selection and exit to play mode.
