FRONT PANEL CONTROL FUNCTIONS
CLIP Monitors signal level at seven points of the
circuit. To prevent unwanted clipping set
levels so LED's light only during largest
transients. NOTE: Very short overloads may
not always trigger the clip LED's.
INPUT Accepts instrument level 1/4" phone jack.
OUTPUT LEVEL Sets volume without affecting tone or amount
of distortion.
LED DISPLAY Displays selected program number, MIDI
channel number, and mapped program
number in play mode. Displays selected
parameter's current value in edit mode.
DUAL FUNCTION CONTROLS
IN PLAY MODE
PRESET Selects Factory Presets storage register
BANK Enter a bank number (0 to 25) by using
the up or down arrows. After bank selection,
you must select the "ones" digit using the
buttons labeled (0 to 9) to exit bank select
mode.
0 THRU 9 Selects the "ones" digit of the program
number.
MIDI CHNL Selects the MIDI channel edit mode. Use up
or down arrows to select MIDI channel I to
16, ALL (OMNI) or OFF.
INTERNAL PRGM Selects the user program storage register.
MIDI PRGM Selects the MIDI Mapping storage register.
IN EDIT MODE (NOTE: These buttons have other functions in "Dictionary mode" (see page 34) or
when editing continuous controllers (disscussed in Version 2 release notes).
INPUT Adjusts the amount of gain into the
corresponding voice (Tube or Solid State.)
CONTOUR Allows user to chose one of the six available
contour filter curves for the corresponding
voice (Tube or Solid State.)
OVERDRIVE Adjusts amount of overdrive (distortion. )
MASTER Adjusts the output level for the corresponding
voice (Tube or Solid State), and its mix
relationship with the other voice.
COMPRESSOR Adjusts compressor ratio, threshold, and gain
(compressor output level.)
LO Shelving type EQ, +/- 14dB 50Hz
LO MID Semi parametric type EQ, +/- 14dB @ 54Hz -
166Hz
MID Semi parametric type EQ, +/- 14dB @ 170Hz
- 545Hz
