Setting up
MIC jack
You can connect your microphone with the Mic socket.Please adjust the volume button to get proper
input level when you use the microphoe.
USB midi jack
USB disk jack
You can connect the piano with your computer with the USB MIDI socket.With your favorate music editor
software,you can melodize,record,or just play for fun.
You can connect your USB DISK to piano with the USB socket,to store the recorded MIDI files you
played with the digital piano,or download the MIDI files from the USB DISK,for the purpse of revise
or teaching and practice.
Power jack
This piano use 120V power supply,pease check the voltage suitable for the piano.
To connect the digital piano with other devices,please pull off the power pin,and power off the
piano.
Before power off the piano,please turn the volume control button to the least
Fuse
It's strongly recommened you invite the professional persons which farmiliar with s to change the
fuse if it's broken.You must use the fuse of 1.5A currency.
HEAPHONE LINE MIC
USB MIDI USB
DISK
OUT INAB
AC 120V
FUSE
02
LINE OUT
Stereo System
PHONES jack
A standard pair of stereo headphones can be plugged into this jack for private listening. The internal stereo
speakersystem will be automatically shut off when a head phone is plugged into the PHONES jack. DO NOT
listen with the headphone at high volume for long periods of time. Doing so may cause hearing loss.
CAUTION
Connect the piano to external
ment only after turning off the
evices. To prevent
damage to the speakers, set the
volume of the external devices at
the minimum setting before
connecting them. Failure to do so
may result in electric shock or
equipment damage.
equi-
p
power of all d
