5.3 Output To Satellite
Connect the LEFT and RIGHT OUTPUT TO SATELLITE jacks to the
inputs of the left and right main powered speakers or the inputs of the
amps powering the main speakers. Again, when using two subwoofers
(one for each channel), connect only the respective channel.
Both the RCA and XLR outputs have the same output level, and do not
apply any gain change to the satellite signal. The output is a buffered
copy of the input (however, a 80Hz high pass filter may additionally
be engaged).
Please note:
The Satellite Outputs are not active (do not carry any signal) when the Subwoofer is in
Standby Mode. This means that when both the Subwoofer and the Satellites are in Standby
Mode, an input signal is needed.
5. Connecting the SubF Subwoofer
