Adam F5 User Manual

1 = Long term sinusodial amplifier output power for 10 min.; with rated mains voltage, into 3.7R (F5/F7) or 5.2R (SubF), 1% THD
2 = Short term peak amplfier output power for 20 msec.; with rated mains voltage, into 3.7R (F5/F7) or 5.2R (SubF), 10% THD
3 = Volume Control at „0dB“ position delivers same acoustic output level to any ADAM AX series speakers at „0dB“ position.
4 = F5 + F7 models: a cable plugged into the RCA input jack will disable the XLR/TRS input.
5 = For 90dBSPL output @ 1m, free field, volume control fully turned up
6 = No clipping of input circuitry ahead of volume control (Hi Shelf Control centered) and in satellite outputs.
7 = 100Hz...1kHz bandwidth
8 = After switch-on with an input signal of 30mVrms for 1 second
9 = Usable ranges : 90...130V and 180...260V. Note that output powers will scale with mains voltage.
10 = In Standby Mode
11 = In Operating Mode, but idle (without input signal).
12 = Rated maximum with full acoustic output
F5 F7 SubF
Tweeter X-ART X-ART –
Velocity Transfer Ratio 4:1 4:1 –
Woofer 127 mm / 5“ 177 mm / 7“ 203 mm / 8“
Woofer Material Glass Fibre/Paper Glass Fibre/Paper Glass Fibre/Paper
Built-in Amplifiers 2; Type A/B 2; Type A/B 1; PWM
Woofer Channel
1/2
25 W/35 W 60 W/85 W 110 W/150 W
Tweeter Channel
1/2
25 W/35 W 40 W/55 W –
Volume Control
3
-∞ to +6 dB -∞ to +6 dB -∞ to +12 dB
High Shelf EQ > 5 kHz ± 6 dB ± 6 dB –
Low Shelf EQ < 300 Hz ± 6 dB ± 6 dB –
Frequency Response 52 Hz - 50 kHz 44 Hz - 50 kHz 30 Hz - 50...120 Hz
Max. Peak Acoustic Output in 1m ≥106 dBSPL / per pair ≥109 dBSPL / per pair ≥107 dBSPL
Inputs
4
XLR/TRS, RCA XLR/TRS, RCA XLR/TRS, RCA
Satellite Outputs / Output Gain – – XLR, RCA / 0dB
Input Sensitivity
5
220 mVrms (-13 dBV) 220 mVrms (-13 dBV) 110 mVrms (-19 dBV)
Input Impedance
40 kOhms (RCA) /
10 kOhms (XLR/TRS)
40 kOhms (RCA) /
10 kOhms (XLR/TRS)
40 kOhms (RCA) /
10 kOhms (XLR/TRS)
Input Headroom
6
> 3 Vrms > 3 Vrms > 3 Vrms
Common Mode Rejection (XLR/TRS Inputs) > 40 dB > 40 dB > 40 dB
Threshold of Automatic Standby Signal
Detector
7
3 mVrms (-50 dBV) 3 mVrms (-50 dBV) 3 mVrms (-50 dBV)
Hold Time of Standby Detector before
Switch-off
8
> 20 min. > 20 min. > 20 min.
Mains Power Supply (User-selectable)
9
115 V, 50...60 Hz
230 V, 50...60 Hz
115 V, 50...60 Hz
230 V, 50...60 Hz
115 V, 50...60 Hz
230 V, 50...60 Hz
Power Consumption
10/11/12
<0.5 W / <15 W / 75 W <0.5 W / <15 W / 100 W <0.5 W / <15 W / 150 W
Weight 6.8 kg / 15 lb. 9 kg / 19.8 lb. 9.9 kg / 21.8 lb.
Magnetically shielded no no no
Height x Width x Depth
290 x 185 x 230 mm
11.5“ x 7.5“ x 9“
321 x 225 x 266 mm
2.5“ x 9“ x 10.5“
350 x 250 x 341 mm
14“ x 10“ x 13.5“
Operating temperature
0° C to 40° C
(32° F to 104° F)
0° C to 40° C
(32° F to 104° F)
0° C to 40° C
(32° F to 104° F)
Storage temperature
-30° C to 70° C
(-22° F to 167° F)
-30° C to 70° C
(-22° F to 167° F)
-30° C to 70° C
(-22° F to 167° F)
Humidity Max. 90 % not condensing Max. 90 % not condensing Max. 90 % not condensing
14 . Technical Data / Technische Daten

Adam F5 Specifications

General

Brand	Adam
Model	F5
Category	Speakers
Language	English
