Adam S3A - Technical Specifications

15
English
Woofer/Subwoofer 1/1
Basket ø 7“ HexaCone®
Voice coil ø 39 mm
ART Tweeter 1
Diaphragm area 71 cm
2
Equivalent diaphragm ø 9,5 cm
Speed transformation ratio 4:1
Diaphragm weight 0,17 g
Built-in ampliers 3 (Class 1)
AC Voltage
100-120 V~, 50/60 Hz
*3
220-240 V~, 50/60 Hz
*3
Subwoofer/Woofer channel (*1/*2) 2 x 150 W / 200 W
Tweeter channel (*1/*2) 150 W / 200 W
General Data
Frequency response (± 3 dB) 32 Hz - 35 kHz
Crossover frequency 150 / 1800 Hz
THD >80 Hz at 90 dB in 1 m ≤ 0,5 %
Short time sine wave acoustic
output at 1 m, 100 Hz - 3 kHz
≥114 dB
Max. peak acoustic output per pair
with music
≥124 dB
Impedance 10 kΩ
Height x Width x Depth 240 x 500 x 320 mm
Weight 16 kg (35.3 pounds)
Warranty 2 years
Input XLR (balanced)
Operating temperature 0° C bis 40° C (32° F bis 104° F)
Storage temperature -30° C bis 70° C (-22° F bis 167° F)
Humidity Max. 90% not condensing
11 . Technical Data
ADAM S3A - active 3-ways bass reex loudspeaker
*1 = long term IEC 265-8-Wrms / 10 min
*2 = nominal IEC 265-8 = Peak Power 5 µsec
*3 = pay attention to the selected voltage on the rearside of the speaker
