Components Overview
4
• User Guide
• Installation Template
• Card Keys (x4)
• Mounting Screws
Due to the nature of the Magic Mirror, exposure to intense direct light may change
the color of the product over time.
Front Body
Single Door Magnet Extension type deadbolt
10mm door thickness
gasket (13/32”)
Back Body Strike for Double Doors
Basic Contents
Specifications
Parts Specifications Remarks
Front Body 9/16(D) x 2-7/8(W) x 7-5/16(H) inches
14(D) x 73(W) x 186 (H) millimeters
Operating Temperature:
5 to 130 °F
-15 to 55 °C
Back Body 1-15/16(D) x 3-1/16(W) x 7-1/2(H) inches
49(D) x 77.5(W) x 190.5(H) millimeters
Battery 1.5 AA Alkaline batteries x4
Operating voltage: 4.5 – 6 V
Effective for 1 year
(based on 10 daily uses)
