Adaptec 5805 - Adaptec RAID 5445;5445 Z LED and I2 C Connector Specification

Appendix F: Controller LED and I2C Connector Quick Reference ● 115
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J4:
● Adaptec RAID 5405 Status LED Board Connector: Molex 10-89-7162 or equivalent
● Status LED Mating Cable Connector: Molex 22-55-2161 or equivalent
J14 (Adaptec RAID 5405 only):
Adaptec RAID 5445/5445Z LED and I2C Connector
Specification
● Adaptec RAID 5445/5445Z Activity LED Header Connector: Molex 10-89-7162 or
equivalent
● Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
Note:
For Adaptec RAID 5445, header J2 is a 16-pin connector (pins 1-16). For Adaptec RAID
5445Z, header J2 is an 8-pin connector (pins 1-8 only).
J4 Pin Number Signal
3I2C Clock
2Ground
1I2C Data
J14 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 STATUS CN0, LANE 0LED Cathode 1
3 +3.3V LED Anode 4
4 STATUS CN0, LANE 1LED Cathode 3
5 +3.3V LED Anode 6
6 STATUS CN0, LANE 2LED Cathode 5
7 +3.3V LED Anode 8
8 STATUS CN0, LANE 3LED Cathode 7
2228800-R ASR-5445 RoHS Kit
2244900-R ASR-5445/512MB RoHS SGL
2267000-R ASR-5445Z RoHS Single
J2 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 ACTIVITY CN0, LANE 0 LED Cathode 1
3 +3.3V LED Anode 4
4 ACTIVITY CN0, LANE 1 LED Cathode 3
